properties
◎The table has complete equipment. It is easy to install, and can be used to produce immediately except special environment.
◎The mixing room is thoroughly sealed up, and it is sage, simple and convenient to operate.
◎The machine adopts the drop. type for materials to come out. It is easy and simple to change colors and rinse.
specification
|
|
|
MAIN MOTOR(HP)
|
|
TILTING MOTOR(HP)
|
|
MACHINE DIMENSIONS
L × W × H (mm)
|
|
APPROX WEIGHT weight
|
|
GDK-3 |
|
7.5/10 |
|
0.5 |
|
1750 × 1000 × 1840 |
|
1150 kgs |
|
GDK-5 |
|
15 |
|
1 |
|
1790 × 1020 × 1950 |
|
1340 kgs |
|
GDK-20 |
|
30/40 |
|
2 |
|
2345 × 1325 × 2475 |
|
3200 kgs |
|
GDK-35 |
|
50/75 |
|
3 |
|
2870 × 2055 × 2630 |
|
5060 kgs |
|
GDK-55 |
|
75/100 |
|
3 |
|
3180 × 2315 × 2910 |
|
7100 kgs |
|
GDK-75 |
|
100/125/150 |
|
3 |
|
3345 × 2665 × 3355 |
|
9100 kgs |
|
GDK-110 |
|
150/175/200 |
|
5 |
|
3700 × 2935 × 3280 |
|
11000 kgs |
＊ Spec are subiect to for betterment
optional equipment
CNC Intensive Production Management System, HMI, Inverter drive motor, Recorder, Auto weighting system, All the models are CE certified.
applications
|
APPLICATIONS
|
|
Field |
|
Typical Products |
|
Materials |
|
|
|
|
Tires、Bumpers、Tubes、Oil seal、Rubber sheet、Rubber hoses、Wet suits、Golf balls、Beach sandals、Erasers、Sash、Rubber tiles、etc. |
|
|
|
(rubber material) NR、IR、IIR 、BR、NBR、HNBR、EPDM、 SBR、EVA、SILICA、VITON、TPR (SBS、BEBS)、SILICONE |
|
|
|
|
(Filler/compounding ingredient) Carbon black、Calcium Carbonate、talc、Oil、curing agent、etc. |
|
|
|
|
|
|
Plastic compounds、Engineering plastic、Plastic molds、Plastic molds for building、Materials、Electric wire insulations、etc. |
|
|
|
(Plastic material) HDPE、LDPE、PP、EVA、Thermoplastic elastomeric、PVC、PS、ABS、Thermosetting resin etc. |
|
|
|
|
(Filler/compounding ingredient) Carbon black、Calcium carbonate、 Talc、 etc. |
|
|
|
|
|
|
Ink、Pigment masterbatch、curing agent masterbatch、Foaming agent masterbatch、etc. |
|
|
|
(Compounding ingredient) Pigment、carbon black、Foaming agent、Cross-linking agent、Curing agent、Flame retardant (Base polymer) HDPE、LDPE、PP、PVC、PS、ABS、etc. |
|
|
|
|
|
Special containers、Machine components、Magnets、Magnetic、tapes、etc. |
|
|
|
Alumina、Zirconia、Silicon carbide、Metallic powder、Mica、Polymer、etc. |
|
|
|
|
|
Toner for copiers、Polymer blend、Mixing wood flour or rice hull with polymer、Abrasives and wax、Material of pencil leads、Cork、etc. |
|
|
